Panel Mount DT/AT Series connectors with MoistureBlock® Built-In
The DT-MB Pro™ Connector Series is a specially designed DEUTSCH DT and Amphenol AT series panel mount connector, featuring IP68 moisture protection, and DSM&T’s proprietary anti-wicking process, MoistureBlock®, ensuring total moisture protection, inside and out.
A replaceable anodized aluminum housing enhances the strength of the connection point and provides a simplified connector repair process without opening the assembly.
Available in 2-way, 3-way and 4-way, the DT-MB Pro™ is cross-compatible with Deutsch’s DT series and Amphenol’s AT series automotive connectors.
- Replaceable Face for easy field-repairs
- Anodized Aluminum and Molded TPV
- IP68 Rating
- 13AMP Contact Current Rating
- Use with GXL, TXL, UL 1007 and UL 1015; 14-20 AWG. Custom Lengths.
Deutsch DT / Amphenol AT Series Compatible
- 2-Way is Equivalent to DT04-2P / AT04-2P. Mates with DT06-2S / AT06-2S.
- 3-Way is Equivalent to DT04-3P / AT04-4P. Mates with DT06-3S / AT06-3S.
- 4-Way is Equivalent to DT04-4P / AT04-4P. Mates with DT06-4S / AT06-4S.
SPECIFICATIONS
